Description
E1 W FP 4p HR-HR new
Dimensions
-
- Product Net Width: 414mm
-
- Product Net Height: 461mm
-
- Product Net Depth: 396.5mm
-
- Product Net Weight: 36kg
Container Information
-
- Package Level 1 Units: 1 piece
-
- Package Level 1 Gross Weight: 40 kg
-
- Package Level 1 EAN: 8015644609139
Additional Information
-
- Number of Poles: 4
-
- Product Main Type: SACE Emax
-
- Product Name: Fixed Part
-
- Product Type: FP
-
- Rated Voltage (Ur): 690 V
-
- Standards: IEC 60947
-
- Sub-type: E1
-
- Terminal Connection Type:
- Withdraw able Circuit-Breakers
Rear flat Horizontal
-
- Version: W FP
Certificates and Declarations (Document Number)
-
- Data Sheet, Technical Information: 1SDC200006D0209
-
- Declaration of Conformity – CE: 1SDL000165R0013
Classifications
-
- ETIM 4: EC000228 – Power circuit-breaker for trafo/generator/installation prot.
-
- ETIM 5: EC000228 – Power circuit-breaker for trafo/generator/installation prot.
-
- Object Classification Code: Q
-
- UNSPSC: 39120000
