G5-METAL CLAD VACUUM CIRCUIT BREAKERS–12KV/24KV/36KV

    TECHNICAL DATA

    Rated Voltage kV 3 . 6 / 7 . 2 / 1 2 24 36
    Rated Current A 4 0 0 A t o 2 5 0 0 A 400A to 2000A 400A to 2000A
    Insulation Level kV / kVp 1 2 / 2 8 / 7 5 24 / 50 / 125 36 / 70 / 170
    Short time withstand current kA 1 3 . 1 / 2 5 / 4 0 25 / 40 25 / 31.5
    Duration Secs 3 3 3
    Symmetrical Breaking Current kA rms 1 3 . 1 / 2 5 / 4 0 25 / 40 25 / 31.5
    Making Current kA p 31.25 / 62.5 / 100 62.5 / 100 62.5 / 78.75
    Opening time Secs < 50 < 50 < 50
    Closing time Secs < 75 < 75 < 75
    Rated Frequency Hz 50 50 50
    W x D x H Mm 800x1750x2100 1000x1750x2100 1200x2325x2100
    Duty Cycle —           O-0.3 Sec–CO–3 min–CO         —
    Enclosure Degree of Protection

    –  Indoor

    –  Outdoor



    IP 4X IP 55



    IP 4X IP 55



    IP 4X IP 55
    SKU: SKU80 Categories: , Tags: , ,

    Description

    Air Insulated Vacuum Circuit Breakers control all switching duties in medium voltage distribution systems.They represent an attractive solution as a key breaking current for application in enclosed Switchgear, Ring Main Unit and Compact Substations.

    APPLICATION

    • Power Transformer Protection
    • HT Capacitor Bank Protection
    • DOL starting of HT Motors
    • Generator Protection
    • Feeder & Line Protection.
